- ARBOR PRESSES
- For all production and assembly applications
- Precision cut steel rams and pinions for accurate operation
- Tables and slotted table-plates are flat and parallel to provide accurate support
Every JET arbor press is made of a heavy ductile iron casting that offers incredible strength and rigidity to the overall framework. The base, ram housing, framework and 4 position bottom plate are precision machined for unquestioned accuracy.
- Capacity (Tons): 2
- Overall Dimensions (L x W xH) (In.): 15-3/4 x 10 x 17-1/2
- Weight (Lbs.): 68
- Capacity Over Table (In.): 7-1/2
- Anvil Diameter (In.): 6-11/16
- Size of Ram (In.): 1-1/4 x 13
- Diameter of Work (In.): 10-3/4
- Arbor Press Height (In.): 16-1/4
- Base Size (In.): 6-3/8 x 15-3/4
- Ram Bore (In.): 1/2
- Travel of Ram (In.): 9
- Approx. Pressure (Tons): 2
- Height: 10.0000
- Length: 18.0000
- Weight: 61.0000
- Width: 22.0000
